Specifications
| D-2350 | |
|---|---|
| Description | D-2350 |
| Size | 1U |
| Number of Output CH | 2 |
| Output Connection Type | Speakon & Binding Posts |
| Output Configuration | 2x350W RMS @ 8Ω |
| Max Output Power | 2x570W @ 4Ω |
| Input Power | 314W |
| Frequency Responses | 50Hz - 20kHz, +0/-1dB |
| Input Impedance | 20kΩ (balance) / 10kΩ2 (unbalanced) |
| Damping Factor | >500 (10Hz - 400 Hz @ 8Ω) |
| THD+Noise | <0.05% @20Hz - 20kHz |
| SNR | >110dB |
| AC Mains Requirement | 100-240V @ 50-60Hz |
| AC Main Connector | AC Socket Connector (IEC) |
| Dimensions (W*H*D) | 520mm X 385mm X 90mm |
| Shipping Weight | 3.60 KG |
| D-4350 | |
| Description | D-4350 |
| Size | 1U |
| Number of Output CH | 4 |
| Output Connection Type | Speakon & Binding Posts |
| Output Configuration | 4x350W RMS @ 8Ω |
| Max Output Power | 4x570W @ 4Ω |
| Input Power | 157W |
| Frequency Responses | 50Hz - 20kHz, +0/-1dB |
| Input Impedance | 20kΩ (balance) / 10kΩ2 (unbalanced) |
| Damping Factor | >500 (10Hz - 400 Hz @ 8Ω) |
| THD+Noise | <0.05% @20Hz - 20kHz |
| SNR | >110dB |
| AC Mains Requirement | 100-240V @ 50-60Hz |
| AC Main Connector | AC Socket Connector (IEC) |
| Dimensions (W*H*D) | 520mm X 385mm X 90mm |
| Shipping Weight | 4.30 KG |
