5-Zone Mixer Amplifier

5-Zone Mixer Amplifier with MP3/FM Tuner/Bluetooth

The KMA-8120-Z5 is a versatile and high-performance 120W mixer amplifier designed for professional audio distribution. Combining a built-in MP3 player, FM tuner, and Bluetooth connectivity, it provides an all-in-one solution for managing multi-zone audio with ease and precision.

  • Retail
  • School
  • Restaurants
  • Offices
  • Public Address System

Enquire about this range Compare the models

Models

Compare

This range has 5 models. Choose up to four to set side by side.

Specification KMA-8120-Z5 KMA-8240-Z5 KMA-8360-Z5 KMA-8500-Z5 KMA-8650-Z5
Rated output power 120W 240W 350W 500W 650W
Output 70V 38Ω 70V 19Ω 70V 14Ω 70V 10Ω 70V 7.53Ω
AUX output level 0.775V (0dBV) 0.775V (0dBV) 0.775V (0dBV) 0.775V (0dBV) 0.775V (0dBV)
5 Zone Output 100V 100V 100V 100V 100V
Extra Input SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector
Frequency response 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB)
T.H.D. <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power
Muting Function MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB
Controls Volume, tone/treble, mute, power Volume, tone/treble, mute, power Volume, tone/treble, mute, power Volume, tone/treble, mute, power Volume, tone/treble, mute, power
Cooling Fan DC 12V FAN DC 12V FAN DC 12V FAN DC 12V FAN DC 12V FAN
LED indicator AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10
Power supply AC220~240V, 50-60Hz AC220~240V, 50-60Hz AC220~240V, 50-60Hz AC220~240V, 50-60Hz AC220~240V, 50-60Hz
Power consumption 185W 350W 485W 675W 878W
Power cord (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard)
Product dimension (mm) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D)
Packaging dimension (mm) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D)
Net weight (kg) 11.5 13.8 14.5 15.5 15.88
Packaging weight (kg) 13.10 15.40 15.80 17.20 17.58
