Mixer Amplifier Single Zone

Mixer Amplifier with MP3/FM Tuner/Bluetooth

The KMA-8120 is a powerful and versatile mixer amplifier designed for professional audio installations, delivering reliable performance for commercial spaces, public address systems, and multi-source audio environments. Combining amplification, media playback, and flexible connectivity, it offers an all-in-one solution for seamless sound management.

  • Retail
  • School
  • Restaurants
  • Offices
  • Public Address System

Enquire about this range Compare the models

Models

Compare

This range has 4 models. Choose up to four to set side by side.

Specification KMA-8120 KMA-8240 KMA-8360 KMA-8500
Rated output power 120W 240W 350W 500W
Output 70V 38Ω 70V 19Ω 70V 14Ω 70V 10Ω
AUX output level 0.775V (0dBV) 0.775V (0dBV) 0.775V (0dBV) 0.775V (0dBV)
Single Zone Output 100V 100V 100V 100V
Extra Input SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector SD slot, USB slot, RCA connector
Frequency response 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB) 60Hz-15KHz (±3dB)
T.H.D. <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power <0.5% at 1KHz, 1/3 rated output power
Muting Function MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB MIC1 overrides other input signals at 0~30dB
Controls Volume, tone/treble, mute, power Volume, tone/treble, mute, power Volume, tone/treble, mute, power Volume, tone/treble, mute, power
Cooling Fan DC 12V FAN DC 12V FAN DC 12V FAN DC 12V FAN
LED indicator AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10 AC: POWER, level: 2、4 6、8 10
Power supply AC220~240V, 50-60Hz AC220~240V, 50-60Hz AC220~240V, 50-60Hz AC220~240V, 50-60Hz
Power consumption 185W 350W 485W 675W
Power cord (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard) (3×0.75 mm2)×1.5M (standard)
Product dimension (mm) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D) 89(H)×483(W)×366(D)
Packaging dimension (mm) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D) 185(H)×520(W)×435(D)
Net weight (kg) 11.5 13.8 14.5 15.5
Packaging weight (kg) 13.10 15.40 15.80 17.20
